Max Tilt

Max-Tilt Tables

Max-Tilt tables are designed for those applications where tilting the load provides for improved access to the product. Tables availble with 45° or 90° tilt.

Max-Tilt tables are electric hydraulic with the 45° models powered up and gravity down, while the 90° models are powered both up and down with double acting cylinders.

With capacities of 2,000 - 6,000 lbs., the Max-Tilt series can handle most applications.

Standard Features


  • 1.5 HP motor. 115/230 volt single phases or 230/460 3 phase voltage. Motor is internally mounted on most models and externally mounted on table sizes with 24" wide base.
  • 10' power cord standard (connector not included)
  • Hydraulic gear pump with check valve, solenoid valve, filter and velocity fuse standard
  • Color yellow top with blue frame
  • A 30 amp dedicated circuit is required for 115 volt operation
  • Powered up on 45° and 90° tilt. Gravity down on 45° and powered down on 90° tilt
  • Tilt limit switch
  • Push button magnetic back control box standard with 6' cord
  • Smooth steel deck with 4" high lip on hinge end
  • High quality chrome plated cylinder
  • Control box includes magnetic starter transformer, thermal overload and fuses
  • Designed for surface mount or lift table mounting


Max Tilt Quote






Specifications

45° Max-Tilt Tables
Model Capacity
(LBS)		 Lowered
Height		 Platform Base
Frame		 Up Speed Cylinders Motor
(HP)		 Quote
Form
STD MAX
LPTT-20-45-1 2000 10" 24" x 36" 72" x 72" 24" x 36" 16 sec 1 1.5 Quote
LPTT-20-45-2 2000 10" 32" x 36" 72" x 72" 24" x 36" 16 sec 1 1.5 Quote
LPTT-20-45-3 2000 10" 42" x 42" 72" x 72" 24" x 36" 16 sec 1 1.5 Quote
LPTT-20-45-4 2000 10" 48" x 48" 72" x 72" 24" x 36" 16 sec 1 1.5 Quote
LPTT-40-45-1 4000 10" 24" x 36" 72" x 72" 24" x 36" 19 sec 2 1.5 Quote
LPTT-40-45-2 4000 10" 32" x 36" 72" x 72" 24" x 36" 19 sec 2 1.5 Quote
LPTT-40-45-3 4000 10" 42" x 42" 72" x 72" 24" x 36" 19 sec 2 1.5 Quote
LPTT-40-45-4 4000 10" 48" x 48" 72" x 72" 24" x 36" 19 sec 2 1.5 Quote
LPTT-60-45-1 6000 10" 24" x 36" 72" x 72" 24" x 36" 24 sec 3 1.5 Quote
LPTT-60-45-2 6000 10" 32" x 36" 72" x 72" 24" x 36" 24 sec 3 1.5 Quote
LPTT-60-45-3 6000 10" 42" x 42" 72" x 72" 24" x 36" 24 sec 3 1.5 Quote
LPTT-60-45-4 6000 10" 48" x 48" 72" x 72" 24" x 36" 24 sec 3 1.5 Quote


90° Max-Tilt Tables
Model Capacity
(LBS)		 Lowered
Height		 Platform Base
Frame		 Up Speed Cylinders Motor
(HP)		 Quote
Form
STD MAX
LPTT-20-90-1 2000 10" 24" x 36" 72" x 72" 24" x 36" 20 sec 1 1.5 Quote
LPTT-20-90-2 2000 10" 32" x 36" 72" x 72" 24" x 36" 20 sec 1 1.5 Quote
LPTT-20-90-3 2000 10" 42" x 42" 72" x 72" 24" x 36" 20 sec 1 1.5 Quote
LPTT-20-90-4 2000 10" 48" x 48" 72" x 72" 24" x 36" 20 sec 1 1.5 Quote
LPTT-40-90-1 4000 10" 24" x 36" 72" x 72" 24" x 36" 28 sec 2 1.5 Quote
LPTT-40-90-2 4000 10" 32" x 36" 72" x 72" 24" x 36" 28 sec 2 1.5 Quote
LPTT-40-90-3 4000 10" 42" x 42" 72" x 72" 24" x 36" 28 sec 2 1.5 Quote
LPTT-40-90-4 4000 10" 48" x 48" 72" x 72" 24" x 36" 28 sec 2 1.5 Quote
LPTT-60-90-1 6000 10" 24" x 36" 72" x 72" 24" x 36" 48 sec 3 1.5 Quote
LPTT-60-90-2 6000 10" 32" x 36" 72" x 72" 24" x 36" 48 sec 3 1.5 Quote
LPTT-60-90-3 6000 10" 42" x 42" 72" x 72" 24" x 36" 48 sec 3 1.5 Quote
LPTT-60-90-4 6000 10" 48" x 48" 72" x 72" 24" x 36" 48 sec 3 1.5 Quote


Options


  • Foot control switch
  • Tapered toe guards for pit mount
  • Lowering beeper
  • Raised base
  • Remote power unit
  • Accordian bellows safety skirting
  • Special color
  • Adjustable tilt limit switch
